16A LCD Programmable Underfloor Heating Thermostat with Floor Sensor – White
The 16A LCD Programmable Underfloor Heating Thermostat is a versatile 230V digital room thermostat designed for precise temperature control in compatible electric and water underfloor heating systems.
Featuring a modern backlit LCD display, touch-sensitive controls and flexible 7-day programming, this thermostat provides convenient heating control for residential installations.
With a maximum switching capacity of 16 amps and a 3-metre remote floor temperature sensor included, it offers a practical solution for controlling underfloor heating while maintaining comfortable room and floor temperatures.
Key Features & Benefits
- 16A Switching Capacity – Supports compatible heating loads up to 16 amps at 230V AC.
- 7-Day Programmable Heating – Set individual heating schedules for each day of the week.
- Four Temperature Settings Per Day – Programme different comfort levels throughout the day.
- 3-Metre Floor Sensor Included – Supplied with a remote floor temperature probe.
- Multiple Temperature Sensing Modes – Select air, floor or combined temperature sensing.
- Adaptive Start Function – Learns when to start heating to reach the programmed temperature.
- Backlit LCD Display – Clear temperature readings and straightforward operation.
- Touch-Sensitive Controls – Modern, easy-to-use interface.
- Holiday Mode – Convenient temperature management while you’re away.
- Manual Override – Temporarily adjust the temperature without changing your programmed schedule.
- 12/24-Hour Clock Options – Choose your preferred time format.
- Settings Memory – Retains programmed settings following a power interruption.
- Contemporary White Finish – Suitable for modern home interiors.
Programmable Heating for Everyday Comfort
The 16A programmable underfloor heating thermostat allows you to create a heating schedule that matches your daily routine.
With individual programming for each day of the week and up to four temperature settings per day, you can adjust heating for mornings, daytime, evenings and overnight.
The adaptive start function helps the system reach your chosen temperature at the scheduled time.
This gives you greater control over heating operation and helps avoid unnecessary heating when it is not required.
Air and Floor Temperature Control
This LCD thermostat offers flexible temperature monitoring through three selectable sensing modes:
Air Sensor Mode
Uses the thermostat’s built-in room temperature sensor to control heating according to the ambient temperature.
Floor Sensor Mode
Uses the supplied remote floor probe to regulate floor temperature.
Combined Air and Floor Sensor Mode
Uses room temperature for heating control while monitoring floor temperature, helping protect temperature-sensitive floor finishes when configured correctly.
The included 3-metre floor sensor is particularly useful for electric underfloor heating installations where floor temperature monitoring is required.
Suitable for Electric and Water Underfloor Heating
The 16A LCD thermostat can be used with compatible electric underfloor heating systems, provided the connected heating load does not exceed its electrical rating.
It may also be used with compatible wet underfloor heating control systems where the wiring and switching requirements are suitable.
For electric underfloor heating, always check the total connected load and follow the heating system manufacturer’s installation requirements.
Important: This thermostat requires a wired 230V electrical connection. Installation should be carried out by a suitably qualified person.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | LCD programmable room thermostat |
| Power Supply | 230V AC |
| Maximum Switching Capacity | 16A |
| Programming | 7-day programmable |
| Temperature Settings | Up to 4 per day |
| Temperature Sensing | Air, floor or combined |
| Floor Sensor | Included |
| Floor Sensor Cable Length | 3 metres |
| Display | Backlit LCD |
| Controls | Touch-sensitive keys |
| Adaptive Start | Yes |
| Holiday Mode | Yes |
| Manual Override | Yes |
| Clock Display | 12/24-hour selectable |
| Settings Memory | Yes |
| Colour | White |
| WiFi / Smartphone Control | Not specified |
Frequently Asked Questions
Is this thermostat suitable for electric underfloor heating?
Yes, for compatible 230V electric underfloor heating systems within the thermostat’s 16A switching capacity. Always check the electrical load and installation requirements.
Does the 16A LCD thermostat include a floor sensor?
Yes. A 3-metre remote floor temperature probe is included.
Can I programme different temperatures throughout the day?
Yes. The thermostat supports individual daily programming with up to four temperature settings per day.
Can the thermostat measure both room and floor temperature?
Yes. It supports air, floor and combined sensing modes, allowing the installer to configure temperature control for the heating application.
Does the thermostat remember settings after a power cut?
Yes. The product features programme and settings memory following a power interruption.
Is this a wireless thermostat?
No. This is a wired 230V thermostat. WiFi or smartphone app functionality is not specified for this model.
Why Choose This 16A LCD Underfloor Heating Thermostat?
The 16A LCD Programmable Underfloor Heating Thermostat combines straightforward digital heating control with flexible programming, multiple sensing modes and a supplied floor probe.
Whether you’re installing a compatible electric underfloor heating system or upgrading an existing wired heating control, this thermostat provides a practical and affordable solution.
Buy the 16A LCD Programmable Underfloor Heating Thermostat from The Underfloor Heating Expert, your UK supplier of electric and water underfloor heating systems, thermostats and installation accessories.
